Tanabe Marine H-Series
Model : H - 63,64,73,74,264,273,274,373,374
Compact, medium pressure compressors improved and Progress from our previous Model HC-277 and VH-477 well-known pioneer compressors of our firm being used for chemical plant at early stage.
These highly efficient compressors afford best profit for users and customers.
Pressure: 10~35kgf/cm² (0.98~3.43MPa)
Type: Water-cooled, 1~3 cyl; 2-stage compressors
Capacity: 0.83~7.08m³/min
Tanabe Marine LSHC & LHC -Series
Model : LSHC - 20B, 30B, 40A
LHC - 54A, 54AYN
Compact air compressor having outmost efficiency affords good maintenance ability and easy handling. Best relatability through simple construction gains applauses as the best small compressor in the market.
Pressure: 10~30kgf/cm² (0.98~2.94MPa)
Type: Air-cooled, single or double cyl;
2-stage compressors
Capacity: 4.8~88m³/hr FA
Tanabe Marine VLHH-Series
Model : VLHH - 64A, 74A, 114, 2114
Air-cooled, large capacity, high speed compressors having efficient air cooler, highly reliable air valve. These models are usually epoch-making compressors manufactures under mass production.
Pressure: 20~35kgf/cm² (1.96~3.43MPa)
Type: Vtype, air-cooled,
2~4 cyl; 3-stage compressors
Capacity: 0.95~8.54m³/min
Tanabe Marine VLHH-Series
Model : SWL - 242, 243A
Well-balanced air-cooled high pressure compressor. Fully reliable compressor overcoming heat problem in air-cooled type by superior design technique in cooling of cylinder, head, coolers and others.
Pressure: 30~70kgf/cm² (2.94~6.86MPa)
Type: Vtype, air-cooled,
4 cyl; 3-stage compressors
Capacity: 0.43~1.36m³/min
Tanabe Marine V & SSWL -Series
Model : V - 11, 13
SSWL - 42, 43A
High pressure compressors improved on lubrication system, handling system and others engage for more reliable performance for high pressure charging requirement.
Model V-11, 13 3 Stage Compressors are used for diving bottle charge.
Pressure: 30~70kgf/cm² (2.94~6.86MPa)
Type: Vtype, air-cooled,
4 cyl; 3-stage compressors
Capacity: 0.43~1.36m³/min
Tanabe Marine V & SSWL -Series
Model : V - 11, 13
SSWL - 42, 43A
Medium size, super-high pressure compressors manufactures under mass-production system. Efficient and reliable compressors used for construction and testing of petroleum factory plant, ocean development and other important high pressure fields.
Pressure: 50~300kgf/cm² (4.9~29.4MPa)
Type: Water-cooled,
2 cyl; 3~4 - stage compressors
Capacity: 1.38~2.81m³/min
